DTC U023A: Lost Communication with Front Camera Module [08/2013 - ]: Wiring Diagram
WARNING: This page is about a different car, the 2014 Lexus ES 300h. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Front Camera Module (w/o Dynamic Radar Cruise Control System) Wiring Diagram
