Fuel Level Sensor 2 -G169-, Checking: Procedure
WARNING: This page is about a different variant/trim than selected.
-- Move the front seats all the way forward.
-- Switch off the ignition.
-- Remove the rear bench seat. Refer to BENCH SEAT/SINGLE SEAT, REMOVING AND INSTALLING .
-- Unclip the right sealing flange cover -1- at the tabs in direction of -arrows- using the :3409 .
VERSION 1:
-- Unlock the connector safety catch and disconnect the connector -2- on the right sealing flange.
NOTE:
Ignore -1-.
VERSION 2:
-- Release the connector safety catch to disconnect the connector -1- on the right sealing flange.
NOTE:
Ignore -2-.
