Rear Lid Motor, Removing And Installing: Removing

Fig 1: Identifying Rear Lid Motor

Courtesy of AUDI OF AMERICA, LLC

-- Remove the left luggage compartment side trim panel, refer to Luggage Compartment Trim Panels .

-- Disconnect the connector from the motor.

-- Remove the bolt -2- from the hinge.

-- Just loosen the nuts on the motor.

-- Remove the right nut -7- from the motor.

-- Remove the motor from the impact absorber -6- toward the right.
