Component Location Overview - Electric And Electronic Components
WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2018 Audi S6, 2018 Audi A6 Quattro, 2018 Audi A6, 2017 Audi S6, and 2017 Audi A6 Quattro. However, it is still accessible from the selected car via links, so may be relevant.
- Heating Element
- For leg rest
- With the seat cushion glued on
- Removing and installing. Refer to SEAT HEATING ELEMENT, REMOVING AND INSTALLING .
- Right Rear Seat Blower Fan -V270-
- Market-specific
- Allocation. Refer to the Parts information
- Removing and installing. Refer to LEFT REAR SEAT BLOWER FAN, REMOVING AND INSTALLING .
- Passenger Side Rear Seat Right Bolster Heating Element -Z89-
- With the seat cushion glued on
- Allocation. Refer to the Parts information
- Removing and installing. Refer to SEAT HEATING ELEMENT, REMOVING AND INSTALLING .
- Right Rear Bench Seat Heating Element -Z12-
- Heating element sewn into seat cover; if faulty, replace the seat cover. Refer to COVER AND CUSHION, SEPARATING .
- Allocation. Refer to the Parts information.
- Passenger Side Rear Seat Left Bolster Heating Element -Z88-
- With the seat cushion glued on
- Allocation. Refer to the Parts information.
- Removing and installing. Refer to SEAT HEATING ELEMENT, REMOVING AND INSTALLING .
- Driver Side Rear Seat Right Bolster Heating Element -Z85-
- With the seat cushion glued on
- Allocation. Refer to the Parts information.
- Removing and installing. Refer to SEAT HEATING ELEMENT, REMOVING AND INSTALLING .
- Left Rear Bench Seat Heating Element -Z10-
- Heating element sewn into seat cover; if faulty, replace the seat cover. Refer to COVER AND CUSHION, SEPARATING .
- Allocation. Refer to the Parts information.
- Driver Side Rear Seat Left Bolster Heating Element -Z84-
- With the seat cushion glued on
- Allocation. Refer to the Parts information.
- Removing and installing. Refer to SEAT HEATING ELEMENT, REMOVING AND INSTALLING .
- Left Rear Seat Blower Fan -V271-
- Equipment levels
- Allocation. Refer to the Parts information.
- Removing and installing. Refer to LEFT REAR SEAT BLOWER FAN, REMOVING AND INSTALLING .
- Seat Heating Control Module -J882-
- Allocation. Refer to the Parts information.
- Removing and installing. Refer to Seat Heating Control Module -J882-, REMOVING AND INSTALLING .
- Heating Element
- For leg rest
- With the seat cushion glued on
- Removing and installing. Refer to SEAT HEATING ELEMENT, REMOVING AND INSTALLING .
