Tunnel-side side trim, removing and installing: Notes

WARNING: This page does not describe the selected car, but rather 15 other vehicles, including the 2008 Audi S4, 2008 Audi RS 4, 2008 Audi A4, 2007 Audi S4, and 2007 Audi RS 4. However, it is still accessible from the selected car via links, so may be relevant.

Special tools, testers and auxiliary items required

Fig 1: Special Tool - Engine And Transmission Holder VAS 6095

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Engine and transmission holder VAS 6095

Fig 2: Fixture For Seat Repair VAS 6136

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Fixture for seat repair VAS 6136

Fig 3: Tunnel-Side Side Trim Remove/Install Components

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Removal

Remove seat → Front seats (standard seat), removing and installing .
Mount the fixture for seat repair VAS 6136 on the engine and transmission holder VAS 6095.
Attach the front seat to the fixture for seat repair VAS 6136.
Loosen footwell cover retaining strip from side panel Footwell cover retaining strip, loosening .

Position a screwdriver to head of plastic rivet - 2 - (2x).
Pry out plastic rivet - 2 - (2x) by turning the screwdriver.
Disengage side panel - 1 - toward top.

Installing

Installation is reverse of removal. When doing so, note the following:

Slide footwell fastening strip into side trim bracket Footwell cover retaining strip, loosening
