Torque Converter Seal, Removing And Installing

Special tools and workshop equipment required

Procedure

Fig 1: Removing Shaft Seal

Courtesy of AUDI OF AMERICA, LLC

-- Remove the torque converter, refer to TORQUE CONVERTER, REMOVING AND INSTALLING .

-- Pry out the shaft seal using the Puller - Seal Lever VW681.

NOTE:

The illustration shows a different transmission.

-- Apply ATF to circumference and sealing lips of shaft seal.

-- Install the shaft seal for the torque converter all the way onto the Seal Installer - Torque Converter T10137.

Fig 2: Installing Shaft Seal

Courtesy of AUDI OF AMERICA, LLC
