Lock Carrier Cover, Removing And Installing: Removing

Fig 1: Identifying Bolts And Pull Air Guide Off Air Filter Housing

Courtesy of AUDI OF AMERICA, LLC

-- Remove the lock carrier cover -2- -arrows-.

• If equipped, at the same time release the tab -3-.
• While doing this the retaining tabs -4- will unlock.

-- Remove the cover from the groove on the lock carrier -1-.
