DTC P0852 Neutral Switch Input Circuit High (Mt Model): Wiring Diagram

WARNING: This page is about a different car, the 2012 Subaru Forester. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Neutral Switch Input Circuit High - Wiring Diagram (MT Model)

Courtesy of SUBARU OF AMERICA, INC.

DIAGNOSIS PROCEDURE

Step	Check	Yes	No
1 CHECK INPUT SIGNAL OF ECM. Turn the ignition switch to ON. Place the shift lever in neutral. Measure the voltage between ECM and chassis ground. Connector & terminal (B136) No. 35 (+) - Chassis ground (-):	Is the voltage less than 1 V?	Repair the poor contact of ECM connector.	Go to step 2 .
2 CHECK HARNESS BETWEEN ECM AND NEUTRAL POSITION SWITCH CONNECTOR. Turn the ignition switch to OFF. Disconnect the connectors from ECM and neutral position switch. Measure the resistance of harness between ECM and neutral position switch connector. Connector & terminal (B136) No. 35 - (B25) No. 2: (B136) No. 4 - (B25) No. 1:	Is the resistance less than 1 Ω?	Go to step 3.	Repair the harness and connector. NOTE: In this case, repair the following item: Open circuit in harness between ECM and neutral position switch connector Poor contact of coupling connector
3 CHECK NEUTRAL POSITION SWITCH. Place the shift lever in neutral. Measure the resistance between neutral position switch terminals. Terminals No. 1 - No. 2:	Is the resistance less than 1 Ω?	Repair the poor contact of neutral position switch connector.	Replace the neutral position switch. < refer to SWITCHES AND HARNESS . >
