Front Differential Oil Level

WARNING: This page is about a different car, the 2012 Subaru Forester. However, it is still accessible from the selected car via links, so may be relevant.

Make sure the front differential oil level is at the specified amount. < Ref. to INSPECTION , Differential Gear Oil. >

Fig 1: Front Differential Oil Level Gauge Upper Level And Lower Level
G00514344Courtesy of SUBARU OF AMERICA, INC.
