Convertible Top Compartment -Open- Switch -F407- / Left Convertible Top Compartment Cover Switch -F290-, Removing And Installing: Removing

WARNING: This page does not describe the selected car, but rather 19 other vehicles, including the 2017 Audi S5, 2017 Audi A5 Quattro, 2016 Audi S5, 2016 Audi A5 Quattro, and 2015 Audi S5. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Convertible Top Compartment Switches -F407- / -F290-

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Remove the convertible top compartment cover hinge. Refer to HINGES, REMOVING AND INSTALLING .

-- Open the clips -arrows- and remove the Left Convertible Top Compartment Cover Switch -F290- -1- from its mount.

-- Free up the wiring harness -2- from the convertible top compartment cover emergency release.

-- Free up the wiring harness -1- from the hinge.

Fig 2: Freeing Up Wiring Harness -1- From Hinge

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Remove the bolt -4- and remove the bracket -3-.

-- Open the clips -arrows- and remove the Convertible Top Compartment -Open- Switch -F407- -Pos. 2- from the bracket.
