Front Fog Lamp: Removal

WARNING: This page is about a different car, the 2018 Lincoln Navigator. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: Removal steps in this procedure may contain installation details.

NOTE: LH front fog lamp shown, RH front fog lamp similar.

Remove the front wheels and tires. Refer to: Wheel and Tire .
Remove the fender liner screws.
Torque: 18 lb.in (2 Nm)

Courtesy of FORD MOTOR COMPANY
Remove the screws, the push pins and position the fender liner aside.
Torque: 18 lb.in (2 Nm)

Courtesy of FORD MOTOR COMPANY
Remove the bolts and the front fog lamp assembly.
- Disconnect the electrical connector and harness retainer.

Courtesy of FORD MOTOR COMPANY
