ATF, Draining, 0BF

Special tools and workshop equipment required

• Drip Tray

• ATF plug overview. Refer to GEAR OIL DRAIN AND INSPECTION PLUGS OVERVIEW, 0BF .

-- Remove the ATF check plug -arrow- so that the ATF drains faster.

Fig 1: Locating ATF Check Plug

Courtesy of AUDI OF AMERICA, LLC

-- Remove the ATF drain plug -arrow- and drain the ATF.

Fig 2: Locating ATF Drain Plug

Courtesy of AUDI OF AMERICA, LLC

-- Install the new ATF drain plug -arrow- and tighten. Tightening Specification, refer to -item  16- ATF Drain Plug (See Figure).

-- Fill with ATF in the rear final drive. Refer to ATF, FILLING, 0BE, 0BF .
