Side Trim, Sill Side, Removing and Installing

Fig 1: Side Trim, Sill Side Remove/Install Components

Courtesy of VOLKSWAGEN UNITED STATES, INC.

1 - Front seat

2 - Front trim panel

3 - Screw

4 - Connector

5 - Side trim (sill side)

• Removing

• Remove seat → Seat, Removing and Installing .
• Mount the fixture for seat repair VAS 6136 on the engine and transmission holder VAS 6095.
• Attach the front seat to the fixture for seat repair VAS 6136.
• Remove bolts - 6  - (qty. 2).

• Remove screw - 3  -.
• Disengage the side trim panels - 5  - at the front trim panel - 2  -.
• Pull off side panel - 5  - starting from switch side.
• Disconnect the connector - 4  -.

6 - Screws, (qty. 2)
