Lid Lock Spring

WARNING: This page does not describe the selected car, but rather 18 other vehicles, including the 2016 Audi S4, 2016 Audi A4 Quattro, 2016 Audi A4, 2015 Audi S4, and 2015 Audi A4 Quattro. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Rear Lid Lock Spring
GWWA55-10329Courtesy of AUDI OF AMERICA, LLC
  1. Brake Component
    • No replacement part.
  2. Lid Hinge
  3. Spring
    • Pay attention to the connection points.
