Exhaust Gas Temperature Sensor 3 -G495-, REMOVING AND INSTALLING: Removing

WARNING: This page is about a different car, the 2015 Audi Q7, 2014 Audi Q7, and 2013 Audi Q7. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Engine Cover -Arrows-

Courtesy of AUDI OF AMERICA, LLC

-- Carefully pull the engine cover off the four retaining pins one after the other in direction of -arrows-.

Vehicles without a Selective Catalytic Reduction (SCR) catalytic converter:

Fig 2: Component Location On Plenum Chamber Bulkhead

Courtesy of AUDI OF AMERICA, LLC

-- Disconnect the -4- Exhaust Gas Temperature Sensor 3 -G448- connector.

-- Lay the wires underneath.

WARNING:

When working on the whole exhaust system:

Follow the safety precautions when working on the exhaust system. Refer to EXHAUST SYSTEM SAFETY PRECAUTIONS .

-- Remove the Exhaust Gas Temperature Sensor 3 -G495- -arrow-.

Fig 3: Locating Exhaust Gas Temperature Sensor 3 -G495- -Arrow-

Courtesy of AUDI OF AMERICA, LLC

Vehicles with a SCR Catalytic Converter

-- Remove the connectors -arrow- from the bracket, disconnect them and then free up the wires.

Fig 4: SCR Catalytic Converter Connector Location

Courtesy of AUDI OF AMERICA, LLC

-- Remove the rear noise insulation -2-. Refer to NOISE INSULATION, REMOVING AND INSTALLING .

Fig 5: Identifying Front/Rear Noise Insulation

Courtesy of AUDI OF AMERICA, LLC

-- Remove the Exhaust Gas Temperature Sensor 3 -G495- -1-.

Fig 6: Exhaust Gas Temperature Sensor 3 -G495- Location

Courtesy of AUDI OF AMERICA, LLC

NOTE:

To provide a better illustration, component location is shown from behind with engine removed.

Ignore -1-.
