Left cylinder head cover, removing and installing

WARNING: This page is about a different car, the 2006 Audi A8, 2005 Audi A8, and 2004 Audi A8. However, it is still accessible from the selected car via links, so may be relevant.

Removing

Fig 1: Removing Engine Cover

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Remove engine cover - 1 - and - 2 - upward.
Remove ignition coils → 28 IGNITION/GLOW PLUG SYSTEM .
Disconnect crankcase ventilation hose from cylinder head cover.
Remove toothed belt guard.

Fig 2: LH Cylinder Head Cover Bolt Loosening/Tightening Sequence

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Remove left cylinder head cover bolts in sequence - 12 to 1 -.
Remove cylinder head cover.

Installing

Installation is in reverse order of removal, note the following:

NOTE:

Replace cylinder head cover gaskets and ignition coils if damaged.
Replace bolts for cylinder head cover if gasket is damaged.

Clean sealing surfaces, must be free of oil and grease.

Fig 3: Applying Thin Layer Of Sealant To Edges Of Sealing Surfaces Between Bearing Cap And Cylinder Head

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Apply thin layer of sealant (dia. approx. 5 mm) - arrows - to edges of sealing surfaces between bearing cap and cylinder head.

Sealant

Fig 4: LH Cylinder Head Cove Bolt Loosening/Tightening Sequence

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Tighten cylinder head cover in sequence - 1 to 12 -.

Torque specifications

Component	Nm
Cylinder head cover to cylinder head	10
Toothed belt guard to cylinder head cover	10
