Sill And Tunnel Side Trim Panels Overview

Fig 1: Identifying Sill And Tunnel Side Trim Panels

Courtesy of AUDI OF AMERICA, LLC

1. Front Seat
2. Trim
   • Tunnel side
   • Removing and Installing. Refer to TRIM, TUNNEL-SIDE, REMOVING AND INSTALLING .
3. Expanding Rivet
   • Quantity: 4
4. Trim
   • Sill side
   • Removing and Installing. Refer to TRIM, SILL SIDE, REMOVING AND INSTALLING .
5. Assembly Cover
   • Clipped in
   • Removing and Installing. Refer to ASSEMBLY COVER, REMOVING AND INSTALLING .
6. Bolt
   • 3.5 Nm
7. Trim
   • Removing and Installing. Refer to TRIM, REMOVING AND INSTALLING .
