Windshield Washer Fluid Level Sensor -G33-, REMOVING AND INSTALLING
WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2015 Audi Q7, 2014 Audi Q7, 2013 Audi Q7, 2012 Audi Q7, and 2011 Audi Q7. However, it is still accessible from the selected car via links, so may be relevant.
Special tools and workshop equipment required
- Drip tray
Removal
-- Turn off the ignition and remove the key.
-- Remove right front wheel.
-- Remove front right wheel housing liner, refer to Wheel Housing Liners .
-- Disconnect the connector -1-.
-- Place a drip tray under the windshield washer fluid reservoir.
-- Remove the Windshield Washer Fluid Level Sensor -G33- item -2- from the washer fluid reservoir.
Installation
Install in reverse order of removal. Note the following:
-- Check the sealing grommet -3- for damage.
-- Install the right front wheel housing liner, refer to Wheel Housing Liners .
