Sun Shade, Removing And Installing: Removing

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2015 Audi Q7, 2014 Audi Q7, 2013 Audi Q7, 2012 Audi Q7, and 2011 Audi Q7. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Pull The Sun Shade -1- Slightly Out Of The Door Trim Panel

Courtesy of AUDI OF AMERICA, LLC

-- Turn off the ignition and remove the key.

-- Remove the door trim panel. Refer to REAR DOOR TRIM PANEL, REMOVING AND INSTALLING .

-- Remove insulation in upper area from door trim.

-- Carefully release guide strip -2- at left and right with a small screwdriver.

-- Pull the sun shade -1- slightly out of the door trim panel and remove the guide strip from the door trim panel.

NOTE:

Ignore -arrow-.

-- Remove screws -1 to 5- and -7 to 9-.

Fig 2: Remove Screws -1 To 5- And -7 To 9-.

Courtesy of AUDI OF AMERICA, LLC

-- Remove sun shade -6- by lightly tipping outward -arrow- out of door trim.
