Suction Hoses to Power Steering Pump and Reservoir, 8-Cylinder FSI, Installation Location

Fig 1: Identifying Marking On Suction Hose Aligns With Formed Seam On Pump

Courtesy of VOLKSWAGEN UNITED STATES, INC.

• The marking - P  - on the suction hose - 1  - must align with the formed seam on the pump - 2  - - arrows  -.

Fig 2: Marking On Intake Hose And Marking On Return Hose Aligns With Formed Seam On Reservoir

Courtesy of VOLKSWAGEN UNITED STATES, INC.

• The marking - 3  - on the intake hose and marking - 4  - on the return hose must align with formed seam - 2  - on the reservoir.
