Hood Seal, Removing And Installing
Courtesy of AUDI OF AMERICA, LLC
- Gasket for Lock Carrier
- Apply gasket at left and right on foam piece.
- When doing this, make sure it is applied without gaps.
- Compress excess length of gasket along lock carrier.
- Right Sealing Profile
- Self-adhering, adhesion surfaces must be free of dust and grease.
- Gasket for Plenum Chamber
- Apply gasket at left and right on foam piece.
- When doing this, make sure it is applied without gaps.
- Compress excess length of gasket along front panel of plenum chamber.
- Left Sealing Profile
