HP2 Steel Caliper Bracket Retrofit

As of implementation of the combination sport suspension (8J x 18 wheel), the brake caliper housing of the front brake is equipped with an additional bracket (for all vehicles). If the 8J x 18 wheel is retrofitted and there is no bracket at the brake caliper housing, retrofit according to illustration. See Fig 1 .

Fig 1: Bracke Caliper Bracket (HP2 Steel Caliper, 8J x 18 Wheel)

Courtesy of AUDI OF AMERICA, INC.
