Display group 001

NOTE: Some OBD program text/data generated by control modules may not be recognized by VAG 1551/1552 scan tools with the latest program card. For example: scan tool display shows "text 799", "01529 /references" or similar. In these cases, use VAS 5051 tester instead.

Indicated on display:

Fig 1: Display Group 001, Navigation System IV
G02728594Courtesy of AUDI OF AMERICA, INC.
