Check DTC Memory (function 02): Notes

• Initiate output Diagnostic Test Mode of instrument cluster. See INSTRUMENT CLUSTER ON BOARD DIAGNOSTIC (OBD), INITIATING  .

Display on VAS 5051:

Fig 1: VAS 5051 Tester Display - Checking DTC Memory, Instrument Cluster (1 Of 2)

Courtesy of AUDI OF AMERICA, INC.

• In selection -1-, click on the diagnostic function "02 - Check DTC Memory".

Display on VAS 5051:

Fig 2: VAS 5051 Tester Display - Checking DTC Memory, Instrument Cluster (2 Of 2)

Courtesy of AUDI OF AMERICA, INC.

1. DTC memory content:
   • 0 malfunctions recognized

   or

   • X malfunctions recognized
2. Diagnostic Trouble Code (DTC)
   • DTC
   • malfunction location
   • malfunction type
