Initiating "Read Measuring Value Block": Notes

Display on VAS 5051:

Fig 1: Display On VAS 5051 - Measuring Value Block Reading, Cruise Control (1 Of 5)

Courtesy of AUDI OF AMERICA, INC.

Press selection -1- of vehicle system "01 -Engine electronics".
Wait until the next indication appears on display.

Display on VAS 5051:

Fig 2: Display On VAS 5051 - Measuring Value Block Reading, Cruise Control (2 Of 5)

Courtesy of AUDI OF AMERICA, INC.

Control module identification of Engine Control Module (ECM).
Control module identification of immobilizer

Click on --> button

Display on VAS 5051:

Fig 3: Display On VAS 5051 - Measuring Value Block Reading, Cruise Control (3 Of 5)

Courtesy of AUDI OF AMERICA, INC.

Select diagnostic function "08 - read measured value block" in selection -1-.

Display on VAS 5051:

Fig 4: Display On VAS 5051 - Measuring Value Block Reading, Cruise Control (4 Of 5)

Courtesy of AUDI OF AMERICA, INC.

Enter display group Max. input value = 255

Select function "066" in button field -2- for "Display group number 066" and press Q button to confirm input.

Display on VAS 5051:

Fig 5: Display On VAS 5051 - Measuring Value Block Reading, Cruise Control (5 Of 5)

Courtesy of AUDI OF AMERICA, INC.

Display group 66
1. Display field 1
2. Display field 2
3. Display field 3
4. Display field 4

NOTE: If no display follows, a display field is not assigned.

NOTE: For vehicles with automatic transmission, the voltage supply for the cruise control switch is not switched on until a speed of above 30 km/h is reached with selector lever in position -2-, -3- or -D-. The voltage supply will then be maintained at idle, as long as a driving mode (aside from -1- or -R-) is selected.

Road test vehicle and exceed 30 km at least once. Do not switch off engine upon completion. Leave selector lever in -2-, -3- or -D-.
Engage parking brake.
