Selecting diagnostic function:

WARNING: This page is about a different car, the 2003 Audi S6 and 2002 Audi S6. However, it is still accessible from the selected car via links, so may be relevant.

At this point all diagnostic functions are available.

Select desired function on display.

Fig 1: VAG 5051 Scan Tool Display - Selecting Diagnostic Function
Courtesy of AUDI OF AMERICA, INC.

For further procedure see repair sequences.

NOTE:

The display zones are displayed in function 04 - Basic settings or 08 - Reading measured value block, from the top downward.
If the displays shown in the procedure do not appear in the display:
See operating instructions for vehicle diagnostic, testing and information system VAS 5051.
