Step 8: Diagnosis of aging of oxygen sensors upstream of catalytic converter: Notes
WARNING: This page is about a different car, the 2003 Audi RS 6. However, it is still accessible from the selected car via links, so may be relevant.
Indicated on VAS 5051:
Fig 1: Function Display VAS 5051 - Generating Readiness Code, Diagnosis Of Aging Of Oxygen Sensors Upstream Of Catalytic Converter (1 Of 4)
- - Enter display group
- Use keypad -2- to enter "034" for "Display group number 034" and confirm by touching Q key.
Indicated on VAS 5051:
Fig 2: Function Display VAS 5051 - Generating Readiness Code, Diagnosis Of Aging Of Oxygen Sensors Upstream Of Catalytic Converter (2 Of 4)
- Activate basic setting by touching key -A-.
