Step 6: Diagnosis of tank leak test: Condition

WARNING: This page is about a different car, the 2003 Audi RS 6. However, it is still accessible from the selected car via links, so may be relevant.

Engine idling
Engine coolant temperature greater than 85°C
Intake air temperature lower than 85°C
Fuel tank filler cap opened briefly to release pressure.

Indicated on VAS 5051:

Fig 1: Function Display VAS 5051 - Generating Readiness Code, Diagnosis Of Tank Leak Test (1 Of 2)

Courtesy of AUDI OF AMERICA, INC.

- Enter display group

Use keypad -2- to enter "071" for "Display group number 071" and confirm by touching Q key.

Indicated on VAS 5051:

Fig 2: Function Display VAS 5051 - Generating Readiness Code, Diagnosis Of Tank Leak Test (2 Of 2)

Courtesy of AUDI OF AMERICA, INC.

Activate basic setting by touching key -A-.
Check display in zone -4-.

NOTE:

Test duration for the tank leak test takes approximately 90 seconds.
Should the diagnosis be repeated several times, open the fuel filler cap each time to release pressure in the tank.

DISPLAY GROUP 071: DIAGNOSTIC OF TANK LEAK TEST

	Display zones
	1	2	3	4
Display group 071: Diagnostic of tank leak test
Display	Reed open	-	System Test	Test ON
Significance	Condition Reed-contact (in Leak Detection Pump -V144-)	Fault message	System condition	Diagnosis status
Operating range	Reed open	Small leak	System test	Test OFF Test ON
	Reed closed	Large leak	Measurement	Syst. OK Syst. n.OK
	Reed closed	Syst. not OK	Measurement END	Abort
Specification	Reed open	-	Measurement END	Syst. OK
Note				If "Syst. n.OK" is displayed, interrogate fault memory, see FAULT MEMORY, INTERROGATING AND ERASING

If specification "TEV OK" is obtained in display zone 4:

Touch > key.
Proceed with next step.
