Actuation of coolant fan control 1
WARNING: This page is about a different car, the 2003 Audi RS 6. However, it is still accessible from the selected car via links, so may be relevant.
- Touch > key.
Indicated on VAS 5051:
- - Control element test waiting - Selection of next step required
- 14 - Coolant fan actuation 1
- Touch > key again.
Indicated on VAS 5051:
- - Control element test in progress - Selection of next step permitted
- Coolant fan control module -J293- (at front of engine compartment, directly at fan, on right in direction of travel) slowly increases speed of coolant fan (on right in direction of travel) once to maximum unless--> key is pressed beforehand to select next control element.
If fan does not start up:
- Check coolant fan and Coolant fan control module -J293-.
