Actuation of Secondary air injection pump relay -J299-
WARNING: This page is about a different car, the 2003 Audi RS 6. However, it is still accessible from the selected car via links, so may be relevant.
- Touch > key.
Indicated on VAS 5051:
Fig 1: Function Display VAS 5051 - Final Control Diagnosis (Secondary Air Injection Pump Relay -J299-)
- - Control element test waiting - Selection of next step required
- 3 - Secondary air injection pump relay -J299-
- Touch > key again.
Indicated on VAS 5051:
- - Control element test in progress - Selection of next step permitted
- Secondary air injection pump relay -J299- (in relay carrier in plenum chamber electronics box, refer to wiring diagram) intermittently switches secondary air injection pump motor -V101- on and off for approx. 1 minute if next control element is not selected beforehand by touching--> key.
If secondary air injection pump motor does not run intermittently:
- Check Secondary air injection pump relay -J299-:
