Actuation of Right Electro -Hydraulic engine mount solenoid valve -N145 -

WARNING: This page is about a different car, the 2003 Audi RS 6. However, it is still accessible from the selected car via links, so may be relevant.

Touch > key.

Indicated on VAS 5051:

Fig 1: Function Display VAS 5051 - Final Control Diagnosis (Right Electro -Hydraulic Engine Mount Solenoid Valve -N145 -)

Courtesy of AUDI OF AMERICA, INC.

- Control element test waiting - Selection of next step required

8 - Right Electro-Hydraulic engine mount solenoid valve -N145-

Touch > key again.

Indicated on VAS 5051:

- Control element test in progress - Selection of next step permitted
- This valve is actuated (clicks) for approx. 1 minute if--> key is not touched beforehand to select next control element.

If valve is not actuated (does not click):

Check engine mount solenoid valve:
See LEFT/RIGHT ELECTRO-HYDRAULIC ENGINE MOUNT SOLENOID VALVE -N144- AND -N145-, CHECKING .
