Deactivating CCS

WARNING: This page is about a different car, the 2003 Audi RS 6. However, it is still accessible from the selected car via links, so may be relevant.

Use keypad -2- to enter "16167" and confirm entry by touching Q key.
End function "11 - Encoding II" by touching > key.

Indicated on VAS 5051:

Fig 1: Function Display VAS 5051 - Cruise Control System, Activating/Deactivating (3 Of 5)

Courtesy of AUDI OF AMERICA, INC.

From list -1- select diagnostic function "08 - Reading measured value block".

Indicated on VAS 5051:

Fig 2: Function Display VAS 5051 - Cruise Control System, Activating/Deactivating (4 Of 5)

Courtesy of AUDI OF AMERICA, INC.

- Enter display group

Use keypad -2- to enter "066" for "Display group number 066" and confirm by touching Q key.

Indicated on VAS 5051:

Fig 3: Function Display VAS 5051 - Cruise Control System, Activating/Deactivating (5 Of 5)

Courtesy of AUDI OF AMERICA, INC.

Check display in zone -2-.

DISPLAY GROUP 066: SIGNALS TO ENGINE CONTROL MODULE

	Display zones
	1	2	3	4
Display group 066: Signals to engine control module
Display	xxx km/h	XXXXXXXX	xxx km/h	XXXXXXXX
Significance	ACTUAL vehicle speed	Switch positions	SPECIFIED vehicle speed	Switch positions
Operating range		0 = off 1 = on		0 = off 1 = on
Specification		XXXX0XXX (with CCS not activated) XXXXXXXX (with CCS activated)		XXXX1XXX
Note		Value: X = No significance

End function "08 - Reading measured value block" by touching > key.
Touch "06 - End of output".
Switch off ignition.
