Release cable, removing
Courtesy of VOLKSWAGEN UNITED STATES, INC.
- Remove nipple - 3
- from lever.
- Disengage release cable - 5
- at adjuster wheel - 2
-.
Courtesy of VOLKSWAGEN UNITED STATES, INC.
- Disengage release cable - 5
-.
- Disengage nipple - 4
-.
- Thread release cable out of seat frame.
Courtesy of VOLKSWAGEN UNITED STATES, INC.
- Attach nipple - 3
- to lever.
- Wrap cable around guide roller.
- Engage release cable - 5
- at adjuster wheel - 2
-.
- Turn adjuster wheel - 2
- until cable makes contact with guide roller.
- Attach height adjustment handle.
- Attach seat height adjustment handle. Gas-filled strut should release at approx. half-way point. If necessary, reset adjuster wheel - 2
-.
