Front Passenger's Weight Sensor Output Check After A Vehicle Collision (KA, Kc Models) (2016 2017 2018 2019 2020 2021 2022): Procedure

Front Passenger's Weight Sensor Output Check After a Vehicle Collision

• Make sure all the components of the front passenger's seat are correctly installed.
• Position the front passenger's seat all the way rearward, and adjust the seat-back to the forward most position. Do not move the seat from this position until the output check is completed.
• Make sure nothing is on the front passenger's seat, including aftermarket seat covers or mats.
• Make sure nothing is in the front passenger's seat-back pocket.
• Keep the windows and the moonroof closed (if equipped).
• Make sure the vehicle is on level ground.
• Dehumidify inside of the vehicle with the A/C.
• Do not touch the front passenger's seat during the output check.
• Do not expose the front passenger's seat to sudden temperature changes.
• Make sure all aftermarket devices (amplifiers, fluorescent light, air purifiers, CB or HAM radios, etc.) are turned off.

1. From SRS in the HDS Main Menu, select SWS, then Inspection. In the Inspection Menu, select AFTER A VEHICLE COLLISION. Follow the prompts until the front passenger's weight sensor output check has been completed.

2. Press the engine start/stop button to select the OFF mode.
