Camshaft Gear/Sprocket

Camshaft Sprocket Bolt 90 N-m (9.2 kgf-m, 67 lbf-ft)

Apply new engine oil to the threads of the camshaft pulley mounting bolt (A). Install the back cover (B), then install the camshaft pulley (C).





Set the camshaft pulleys to top dead center (TDC) before bolting them onto the engine block
