Glove Box Removal/Installation

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

1. Remove the passenger's dashboard trim (see PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION  ).
2. Remove the passenger's dashboard side panel (A).
   1. Open the front door.
   2. Gently pry the notch (B) of the panel with the appropriate trim tool to detach the clips.
      Fig 1: Identifying Passenger's Dashboard Side Panel And Clips

      Courtesy of AMERICAN HONDA MOTOR CO., INC.
3. Remove the bolts (A) and the screws (B).
   Fig 2: Glove Box Bolts And Screws With Torque Specifications

   Courtesy of AMERICAN HONDA MOTOR CO., INC.
4. Remove the glove box (A).
   1. Release the hook (B) and pull the glove box by hand to detach the clip.
   2. While holding the glove box, disconnect the glove box light bulb (C) and the keyless access system mode switch connector (D) (if equipped).
      Fig 3: Identifying Glove Box Light Bulb And Keyless Access System Mode Switch Connector

      Courtesy of AMERICAN HONDA MOTOR CO., INC.
5. Install the glove box in the reverse order of removal, and note these items:
   • If the clip is damaged or stress-whitened, replace it with a new one.
   • Make sure each connector is plugged in properly.
   • Push the clip and the hook into place securely.
