Driver's Dashboard Undercover Removal/Installation

NOTE: Take care not to scratch the dashboard and related parts.

Remove the driver's dashboard undercover (A).
1. Turn the lock knob (B) 90°.
2. Gently pull down the rear edge to detach the clips.
3. Pull the undercover away to release the pin (C) from the holder (D).
4. For some models: If equipped with a foot light illumination, disconnect the foot light illumination connector (E).

  Fig 1: Identifying Foot Light Illumination Connector, Lock Knob And Pin
  Courtesy of AMERICAN HONDA MOTOR CO., INC.
Install the undercover in the reverse order of removal, and note these items:
- Make sure the foot light illumination connector is plugged in properly (for some models).
- Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones.
- Push the clips into place securely.
